Name：KOF Bare Frame Style Full Automatic High Speed Slitting And Rewinding Macheine
No：KOF
Performance and Characteristics
This machine is used for slitting and rewinding various large rolling materials such as paper,(kraft paper,cellophane paper,bill paper),double-face adhesive tape,PVC,plastic mater ,etc.
1.This machine use PLC controller, automatic taper tension,central surface reeling.
2.Frequency converter three motor vector control,keeping speedup and stable operation.It has the functions of automatic metering,automatic.
3.With A,B inflatable shaft structures for rewinging;Finished products are automatic loading and unloading.It adopts photoelectric automatic error correction adiustment system for unwinding,anomalistic materials will be easy slit.
4.Equipped with automatic waste paper inhaling blowing device.Automatic material loading by hydraulic system for unwinding.
Main Technical Parameters
|
Model |
KOF-1300 |
FOF-1600 |
KOF-1800 |
|
Max.width of unwinding |
1300mm |
1600mm |
1800mm |
|
Max.diameter of unwinding |
φ1600mm |
φ1600mm |
φ1600mm |
|
Min.width of slitting |
50mm (up to materials) |
50mm (up to materials) |
50mm (up to materials) |
|
Max.diameter of rewinding |
φ1500mm |
φ1500mm |
φ1500mm |
|
Speed |
10-350m/min |
10-350m/min |
10-350m/min |
|
Total Power |
48kw |
50kw |
50kw |
|
power supply |
380V/50Hz |
380V/50Hz |
380V/50Hz |
|
Weight |
10000kg |
12000kg |
13000kg |
|
Overall dimension (LxWxH) |
7500x3500x2200(mm) |
7500x3700x2200(mm) |
7500x3800x2200(mm) |
